Intuitive Form Factors & Design
The Latitude D410 makes a great impression with its slim design, which is only
an inch thick. The system's hard disk drive is internal, with optical media
used externally in the included Dell D/Bay, so you can carry media modules
only when they might be needed. The D/Bay also uses the same modular optical
media solutions as the other Latitude D-Family systems. The D400's Tri-Metal
chassis -- with external magnesium alloy frame -- looks great and helps
provide structural rigidity as well.
Dell Wired and Wireless Communications Solutions
Every Dell Latitude D410 features a wireless networking mini-PCI card, 56K2
V.92 capable modem and 10/100/10003 wired network card as part of the standard
offering. Included in the standard wireless offering is the Intel® Pro
Wireless MiniPCI card. The D400 also features other wireless options,
including a choice of either of the Dell Wireless LAN solutions for those who
demand blazing 802.11a or 802.11g wireless connectivity as well as the Dell
TrueMobileTM 300 integrated Bluetooth solution. With Gigabit3 Ethernet, users
can rest assured that their notebook investments are compatible with future
deployment of Gigabit Ethernet across the network infrastructure.
The Dell Latitude D410 features the latest Intel Pentium M processors, which utilize a new micro-architecture incorporating a power-optimized 400MHz processor system bus and aggressive clock gating designed for high performance & low power. These processors also feature up to 2MB of power managed cache and enhanced Intel SpeedStep® Technology. The D410 also incorporates the Intel® 855GM chipset, which offers integrated graphics capability and USB 2.0 support. The integrated graphics utilizes the system memory as a shared resource for both system memory and graphics needs, dynamically allocating a portion of the memory to graphics based on the graphic demands of the applications currently in use. Up to 64MB of memory can be allocated to graphics, and with integrated video acceleration, you can view high quality, full frame rate DVDs on your notebook or connected external display with exceptionally low power consumption.
Integrated Smart Card Security For a Worry Free
Mobile Experience
While today's notebook computers offer unprecedented power, their mobility
also brings new vulnerabilities, such as unauthorized user access. The
Latitude D400 confronts this problem with an integrated Smart Card reader.
Used in combination with applicable software, Smart Cards provide a robust
solution to user authentication.
| Dell Latitude D410 1.6GHz Intel Wireless Notebook | |
| Specifications | |
| Processors | 1.6GHz Intel Pentium M Processor |
| Chipset | Intel® 855GM Chipset |
| Memory | 1GB DDR2 RAM |
| Displays | 12.1" XGA TFT LCD;1024 x 768 x 16.7 million colors |
| Maximum External Resolution (CRT) | 1600 x 1200 (UXGA) x 16.7 million colors @ 85Hz (Pan mode on LCD/TV if active) |
| Video | Integrated Intel 855GM graphics chipset;
up to 64 MB system memory can be dynamically allocated to graphics needs; 4X AGP support |
| Hard Disk Drive | 40GB Hard Drive |
| Modem | 56K2 v.92 internal modem |
| Wired LAN | 10/100/10003 Ethernet LAN, DMI 2.0 and Wired for Management compliant |
| Wireless LAN | Standard Intel® Pro/Wireless 2200 WLAN (802.11b/g) Mini-PCI Card, Wi-Fi® compatible |
| PC Card Slots | One Type I or Type II |
| Audio | Intel AC97; one integrated speaker |
| Batteries | .Primary battery - Choice of 4-cell/28WHr or 6-cell/42WHr Smart Lithium-Ion with external LED battery gauge and ExpressChargeTM capability Optional second Primary battery - Smart Lithium-Ion (6-cell/42WHr) with external LED battery gauge and ExpressCharge capability |
| Keyboard | 84-Key US; 85-Key Europe; 88-Key Japan; Key travel - 2.6 mm; Key spacing 18mm |
| Pointing Device – Dell DualPoint | .Touch Pad - PS/2 Compatible; Track Stick - PS/2 Compatible |
| Power Supply | 65-Watt AC adapter with cord wrapping |
| System Dimensions/Weight | .26.6mm/1.0" (h) x
294mm/11.6" (w) x 245mm/9.6" (d) With 4-cell battery: 1.69kg/3.73lbs; System with 4 cell battery, D/Bay and CD-ROM module: 2.17kg/4.78lbs With 6-cell battery: 1.77kg/3.90lbs; System with 6 cell battery, D/Bay and CD-ROM module: 2.24kg/4.95lbsWeights vary depending on configurations and manufacturing variability. |
| Serial | .9-pin connector; 16550-compatible, 16-byte buffer |
| Video | 15-hole connector |
| Audio | One headphone and one microphone |
| Universal Serial Bus | .One USB 2.0-compliant connector plus one Dell D/Bay connector (USB 2.0-compliant connector plus power pin; can be used for D/Bay or USB devices) |
| IEEE 1394 | .4 pin, Mini-1394, non-powered |
| Docking Connector | .280-pin for the D/Dock Family Expansion Station & D/Port Family Advanced Port Replicator |
| Modem | RJ-11 port |
| Ethernet LAN | RJ-45 port |
| Infra Red | .1 Infrared sensor compatible with IrDA Standard 1.1 (Fast IR) and IrDA Standard 1.0 (Slow IR) |
| Operating System Versions Available | Windows XP Pro |
| Manufacturer Information | |
| Parts Warranty | 30 Days |
| Labor Warranty | 30 Days |
